Pilot Plants

Chandler Engineering offer custom designs and solutions to fully scalable pilot plants. We provide solutions across various industries for Chemical, Pharmaceutical, Oil and Gas, Renewable Energy, Food and Beverage.

Bench, research and pilot scale processes for:
● CO₂ Recovery and Sequestration
● Refinery Applications
● Biofuels
● Production Simulation
● Small Batch Chemical Manufacturers
● Chemical Processes
● Custom Engineered Projects
Gas Gravitometer

Chandler Engineering’s methane dehydration unit is used for testing the effectiveness of mole sieve materials on the dehydration of methane. The modular design consists of 5 sections: gas inlet, compression, saturation, dehydration and the analysis section.

Specifications:

Saturation Range
Operating Pressure
Operating Temperature
Regeneration Temperature
Gas Flow Rate
Input Voltage

Dimensions
Net Weight


0-2500ppmV @ 1bar, 60°C
90 barg
60°C
300°C
0.5-2.0 m3/hr
230VAC 3-phase, 50/60 Hz, 80A
120VAC 1-phase, 50/60Hz, 20A
508cm W x 190cm D x 205cm H
3000 kg


PRECISION METERING PUMPS
Quizix Precision Pumps are the industry standard for precision delivery of fluids and gases for bench scale and pilot plant applications. Capable of handling fluids, slurries, pastes and gases, these positive displacement pumps provide pulse-free continuous flow at extremely accurate flow rates, pressures or constant volume operating modes.

● Q5000 Series: Ultimate precision for metering of reactant fluids, slurries and pastes
● Q6000 Series: for high flow, large volumes and gas flows
● QX Series: Compact dual cylinders for bench and small scale research applications


MOISTURE/OXYGEN
AMETEK Process Instruments provides a number of analytical solutions to serve users interested in measuring trace to percent levels of moisture, methane, oxygen, hydrocarbons, sulphur species and other elements and compounds in process streams.  With a wide variety of technologies available – including laser absorption (TDLAS), quartz crystal microbalance (QCM), zirconium oxide, ultraviolet and infrared spectroscopy.


WATER ALTERNATING GAS

Single and multi-phase core flood systems are available for EOR applications for Water Alternating Gas (WAG), Steam Alternating Gas (SAG) and chemical and polymer injection. Systems are customized based on user-application and uses Quizix precision pumps to displace fluids in open or closed loop recirculated flows. Many options are available for core holders, accumulators, dP transducers and types of oven enclosures.
This WAG Lab System was design by the most experienced scientists from Petrobras and AMETEK for long term experimental runs for steady state relative permeability.

Customs Brochure
Check out the latest brochure
